How to calculate the thickness of road paints

How to calculate the thickness of road paints and their specifications

The calculation of road paints has two ways:

1- Calculating the thickness of the road paint during the paint work at the site as follows:

hardware  :-

A metal plate with temperature up to about 220 ° C

B) Metric metric scale

C - Electronic balance

Method: -

- The width of the paint (W) and its length on the metal plate (L)

- The metal plate (W1)

- The metal plate is placed under the paint car on the path of the paint line without the glass beads (Glass beads).

- The metal plate with the paint (W2)

- Take the paint density from the certificate of conformity or the certificate of the incoming (S.G)

Accounts: -

The weight of the paint (W) = the difference between W2 and (W1)

Paint size (V) = Weight of paint / paint density (S.G)

Paint thickness (H) = paint size (V) / paint length (L) × paint width (W)

2- Calculation of the thickness of road paints upon receipt:

- Correction of asphalt in place of paint path

- Asphalt height measurement and paint together

- Scrape the paint from the asphalt layer

- Measure the height of the asphalt core

- thickness of road paint = the difference between the height of the corr with the paint and the height of the cor without paint

Specification limits for paint (1.5 to 2.5 mm)

Glass beads specification limit

(Minimum 10% to 15% of the weight of the paint)
